SMART MIXING VALVE SYSTEM
The THERM-O-TRONIK is a smart electronic mixing valve without maintenance, with a powerful algorithm offering you the possibility to adjust the temperature with a set point very accurate of ± 1oC *.
The THERM-O-TRONIK technology is based on a high-performance closed-loop algorithm that does not require any mechanical bimetal thermostat found in traditional mixing valve. Accuracy and response time are greatly superior and the issues of mechanical cartridge blockage are so nonexistent.
The desire temperature set point may be input on the THERM-O-TRONIK directly, or remotely via a interface (sold seperately), or Modbus communication and / or via a web interface.
When the THERM-O-TRONIK is used for the supply of hot water systems in buildings, disinfections can be programmed for automatic starts and / or manual start.
The temperature and disinfection history is saved on an SD card.
Ethernet connectivity inlcuded.
| MODEL | SIZE | Cv | SUPPLY |
| OBMI-050 | 0.5'' | 16 | 24 VDC |
| OBMI-075 | 0.75'' | 24 | 24 VDC |
| OBMI-100 | 1.00'' | 30 | 24 VDC |
| OBMI-150 | 1.50'' | 37 | 24 VDC |
| OBMI-200 | 2.00'' | 65 | 24 VDC |
NOTICE: The THERM-O-TRONIK should not be the last hot water supply device to the users. At the point of users, a Anti-burn cartridge is mandatory.
* With regulated pressure on hot water and cold water accuracy of ± 1oC.
